Suntree 60x80x25cm Steel Enclosure

Description

Overview

The Suntree 60x80x25cm Steel Enclosure is a high capacity wall mounted electrical cabinet.

It is designed for:

• Solar protection devices

• Circuit breakers and isolators

• Monitoring accessories

• Distribution equipment

Use it in residential, commercial, and industrial energy systems.

Why Choose This Enclosure?

The large internal space supports organized component placement.

You can install multiple protection layers inside one enclosure.

Benefits include:

• Reliable wiring structure

• Simplified maintenance access

Built Strong

Manufactured from high strength cold rolled steel.

Finished with durable powder coating for corrosion resistance.

Provides strong mechanical protection and long service reliability.

Where Can You Install It?

Suitable for:

• Inverter mounting areas

• Equipment rooms

• Solar distribution walls

• Sheltered outdoor installation locations

The corrosion resistant coating supports extended performance under demanding installation conditions.

IP65 + IK10 Protection

What Can You Install Inside?

This enclosure supports:

• DC surge protection devices

• AC surge protection devices

• Miniature circuit breakers (MCBs)

• Fuse holders and battery isolators

• Changeover switches

• Monitoring gateways

• Hybrid inverter accessory protection equipment

All for structured solar installations.

Easy Installation

The removable galvanized mounting plate gives installers:

• Flexible positioning of protection components

• Improved cable routing organization during installation

Secure & Accessible

• Lockable front door – Improves equipment safety

• Quick inspection access – Easy when servicing is required

• Reinforced hinges – Maintain door alignment during repeated maintenance cycles

Cable Routing Made Simple

Use the detachable gland plate for professional entry and exit wiring management.

Reliable Sealing

A continuous sealing gasket improves enclosure protection reliability.

This supports stable operation of internal protection devices during long term service conditions.

Best Applications

This enclosure is widely used for:

• Inverter protection panels

• Combiner protection assemblies

• Monitoring control layouts

• Structured solar distribution boards

• Projects requiring large protection spacing for safe installation

  Technical Specifications

  Specification	Details
  Brand	Suntree
  Dimensions (H x W x D)	60 cm x 80 cm x 25 cm
  Material	Powder coated cold rolled steel
  Protection Rating	IP65 (EN60529)
  Impact Resistance	IK10
  Mounting Plate	Galvanized steel, removable
  Door Type	Lockable single door
  Surface Finish	Epoxy polyester powder coating
  Sealing	Continuous sealing gasket
  Cable Entry	Detachable gland plate
  Hinge Design	Reinforced, alignment maintaining
  Mounting Type	Wall mounted
