Compact IP65 steel enclosure for solar protection devices breakers SPDs monitoring units and inverter accessory installations. Strong wall mounted Suntree cabinet with lockable door and mounting plate.
₦41,175.00
The Suntree 25x35x15cm Steel Enclosure is a compact and durable wall mounted electrical cabinet designed to protect solar protection devices, circuit breakers, monitoring accessories, and low voltage control components in residential and commercial installations. Built from high strength cold rolled steel with powder coated surface treatment, this enclosure provides reliable mechanical protection and long service life in demanding installation environments.
Protects solar protection devices, circuit breakers, and monitoring accessories
Suitable for residential and commercial installations
Provides reliable mechanical protection in demanding environments
Ensures long service life
IP65 protection rating – Prevents dust entry and protects against water spray exposure
IK10 impact resistance – Withstands mechanical impacts
Suitable for indoor installations and sheltered outdoor locations such as:
Inverter walls
Solar distribution areas
Equipment mounting zones
Installers benefit from a detachable mounting plate that simplifies:
Device arrangement
Wiring organization during setup
The enclosure supports installation of:
DC surge protection devices
AC surge protection devices
Miniature circuit breakers (MCBs)
Isolators
Monitoring gateways
Communication accessories
Lockable front door – Improves equipment security
Maintains easy maintenance access when required
Strong hinge design – Supports repeated opening cycles without alignment issues
Cable entry is simplified through a removable gland plate located at the bottom section of the enclosure.
A continuous polyurethane sealing gasket improves enclosure reliability and ensures consistent environmental protection during operation.
This enclosure is widely used in:
Solar inverter protection layouts
Combiner protection assemblies
Hybrid inverter accessory installations
Structured distribution panel organization
Its compact footprint allows clean installation where space management is important without sacrificing wiring flexibility.
Installers choose the Suntree steel enclosure because it:
Supports professional cable routing
Improves equipment protection reliability
Maintains organized system layout standards required for modern solar and electrical protection installations
| Specification | Details |
|---|---|
| Brand | Suntree |
| Dimensions (H x W x D) | 25 cm x 35 cm x 15 cm |
| Material | Powder coated cold rolled steel |
| Protection Rating (IP) | IP65 (EN60529) |
| Impact Resistance (IK) | IK10 |
| Mounting Plate | Galvanized steel, removable |
| Door Type | Lockable single door |
| Surface Finish | Epoxy polyester powder coating |
| Sealing | Continuous polyurethane sealing gasket |
| Cable Entry | Removable gland plate (bottom section) |
| Mounting Type | Wall mounted |
| Hinge Design | Heavy duty, repeated opening cycles |
| Compatible Components | DC/AC surge protection devices, MCBs, isolators, monitoring gateways, communication accessories |
| Application Areas | Solar inverter protection layouts, Combiner protection assemblies, Hybrid inverter accessory installations, Structured distribution panels |
| Weight | 6 kg |
|---|---|
| Dimensions | 25 × 35 × 15 cm |
