Description
The Growatt 5.5kWh Lithium-Ion battery is a reliable and efficient energy storage solution for residential and small commercial solar systems. Advanced lithium-ion technology offers high energy density, long cycle life, and seamless integration with growatt inverters for a complete energy management system.
Key Features of the 5.5KWh-Lithium-Ion-Battery.
- High Energy Capacity:
- 5.5kWh of usable energy storage to meet the demands of modern homes and small businesses.
- Long Life Cycle:
- Supports over 6,000 charge/discharge cycles, ensuring years of reliable performance.
- Advanced Lithium-Ion Technology:
- High energy density and efficiency for maximum storage and minimal energy loss.
- Compact and Modular Design:
- Space-saving design with modular scalability to expand capacity by adding more units.
- Seamless Integration:
- Fully compatible with Growatt inverters for optimal performance and monitoring.
- Easy integration into existing solar systems.
- Safety and Reliability:
- Equipped with a robust Battery Management System (BMS) for protection against overcharge, over-discharge, short circuit, and overheating.
- Wide Operating Range:
- Performs efficiently across a broad range of temperatures, suitable for diverse climates.
- User-Friendly Monitoring:
- Works with the Growatt Shine platform for remote monitoring and real-time performance insights.
Specifications
| Parameter | Specification |
|---|---|
| Rated Capacity | 5.5 kWh (usable ~5.12 kWh) |
| Nominal Voltage | 51.2 V DC |
| Operating Voltage Range | 40 V to 58.4 V DC |
| Maximum Discharge Current | ~100 A |
| Cycle Life | > 6,000 cycles at ~93% Depth of Discharge |
| Depth of Discharge (DoD) | ~ 93% |
| Dimensions (L × W × H) | 54.0 cm × 44.0 cm × 13.05 cm (540 × 440 × 130.5 mm) |
| Weight | ~ 45 kg |
| Protection Rating | IP20 |
| Communication Interface | CAN / RS485 |
The Growatt 5.5kWh Lithium-Ion Battery is a dependable choice for sustainable energy storage, offering enhanced efficiency, scalability, and safety for solar energy systems.
